Early detection prevents insulator failure, reducing risk of outages, equipment damage, and safety hazards major.
A broken transmission insulator was identified on an overhead transmission line using the Early Fault Detection (EFD™) system in eastern United States. The abnormal condition was remotely detected and accurately located based on EFD™ system data. The issue was then confirmed through targeted field inspection and optical camera imagery.
The inspection revealed that the top portion of the insulator was completely broken, placing increased mechanical strain on the adjacent insulator. If left undetected and unremedied, the remaining insulator could also fail, allowing the conductor to drop onto the crossarm. This could lead to electrical tracking, flashover, equipment damage, crossarm burn-through, safety hazards for crews and the public, as well as a potential unplanned outage or wildfire risk under certain conditions.
Early detection prevents insulator failure, reducing risk of outages, equipment damage, and safety hazards major.
Accurate fault location enables targeted maintenance, minimizing repair time, operational disruptions, and associated costs overall.
Proactive identification enhances reliability, avoids cascading failures, and improves grid resilience under high stress conditions.
The EFD™ system detected the abnormal electrical activity associated with the damaged insulator and generated alerts in EFD360. These alerts enabled the utility to accurately locate the issue and conduct a focused site investigation. Following visual confirmation, corrective maintenance was performed to replace or repair the affected insulator and restore the asset to a safe operating condition.
By identifying the broken insulator before it caused a failure, the utility reduced the likelihood of an unplanned outage and improved overall system reliability. Early detection also helped avoid potential equipment damage, safety risks, and emergency repair costs, demonstrating the value of EFD™ for proactive transmission asset management.
